General
Model : Landsat 480 C, Landsat 640 C
Classification : Multi-spectral Scope
Thermal Sensor
Type : Uncooled Vox(vanadium oxide)
Landsat 480 C Resolution(pixel) : 480*360
Landsat 640 C Resolution(pixel) : 640*512
Pixel Size(µm) : 12*12
NETD : ≤20mK(0.02℃)
Frame Rate(Hz) : 50
Landsat 480 C Human Detection Distance(m) : 1800
Landsat 640 C Human Detection Distance(m) : 2100
Image Engine : PARD IREA
Landsat 480 C Objective lens(mm) : 35
Landsat 640 C Objective lens(mm) : 45
Landsat 480 C Optical Magnification(x) : 2.5
Landsat 640 C Optical Magnification(x) : 2
Landsat 480 C Digital Zoom(x) : 2/4/6/8
Landsat 640 C Digital Zoom(x) : 2/4/6/8
Landsat 480 C Field of View (HxV) Horizontal : 7.1°
Landsat 640 C Field of View (HxV) Horizontal : 8.8°
Landsat 480 C Field of View (HxV) Vertical : 7.1°
Landsat 640 C Field of View (HxV) Vertical : 8.8°
Landsat 480 C Field of View (HxV) Diagonal : 10.0°
Landsat 640 C Field of View (HxV) Diagonal : 12.4°
Thermal Sensor Focus range : 3m-∞
Visible Light Sensor
Landsat 480 C Resolution(pixel) : 2560*1440
Landsat 640 C Resolution(pixel) : 2560*1440
Pixel Size(μm) : 2.9
Sensitivity(lux) : 0.001
Frame Rate(Hz) : Color mode: 60 / Mono: 30
Image Engine : PARD VLEA
Objective Lens(mm) : 50/70
Optical Magnification(x) : 4.4/6.1
Digital Zoom(x) : 2
Field of View (HxV) Horizontal : 4.8°/3.4°
Field of View (HxV) Vertical : 4.8°/3.4°
Field of View (HxV) Diagonal : 6.8°/4.8°
Visible Light Sensor Focus range : 3m-∞
Display
Type : IPS
Resolution(pixel) : 800*800
Reticle Style : 6
Reticle Color : 4(Red/White/Yellow/Green)
Scene Mode : City/Rain/Forest
Image Mode : WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
Eye Relief(mm) : 100
Diopter Adjustment(D) : -5~+3
Photo / Video
Photo Resolution(pixel) : 1536*1536
Photo Format : .JPG
Video Resolution(pixel) :
Thermal: 768*768/Night Vision: 1440*1080
Video Format : .mp4
Storage(GB) : Micro SD card (Max. 128)
Main Function
LRF Detection Range(yd/m) : 1200/1000
Ballistic Calculator : Yes
PIP : Yes
Gyroscope : Yes
Loop Recording : Yes
Recoil-activated recording : Yes
E-compass : Yes
Shutter : Mechanical shutter
Microphone : Yes
Firmware Upgrade : Yes
IR Illuminator
IR power(W) : 5
IR Illuminating Level : 3 Levels
IR Distance(m) : 350
IR Wavelength(nm) : 850/940
Interfaces
USB Type-C : Yes
HDMI Output : Yes
Connections
WiFi : Yes
Supported Apps : PardVision2
Power Supply
Battery type : Li-ion 21700*1
Output Voltage(V) : 3.7
Operating Time(h) : ≤6
External Power Supply Type : Type-C
Environmental characteristic
Degree of Protection : IP67
Operating Temp(°C/°F) : -20 ~ +50 / -4 ~ +122
Recoil Resistance(J) : 6000
Material
Housing : Aluminum Alloy
Objective lens : All-glass multi-coated lens
Measurement
Product Dimension(L * W * H, mm) : 265*92*90
Landsat 480 C N.W/pcs(with IR illuminator&LRF&battery, g) : 750
Landsat 640 C N.W/pcs(with IR illuminator&LRF&battery, g) : 785
code:
la4c-35/70/lrf ～ la6c-45/70/lrf
