CNC-machined 7075-T6 aluminum housing, hard-coat anodized to Type III MIL-A-8625
Protective 6061-T6 extruded aluminum “crumple” hood
Weight: 12.6 oz. with hood
Unit Size (LxWxH): 95mm x 57mm x 65mm
Large window for fast target acquisition (1.37″ x 1.04″). 90 degree vertical ocular lens to diffuse environmental glare
Lower 1/3rd (1.70″) optical axis height to better align with magnifier/mount ecosystems
0.5-MOA adjustment for windage & elevation
User-configurable circle/dot & red dot reticles (2-MOA dot, 65-MOA ring + dot, 65-MOA ring only)
Powered by a single CR123A cell for 150,000 continuous runtime with 2-MOA dot reticle (Setting 5/10)
Parallax-free LED, unlimited eye relief
Always on unless manually turned off; “set & forget” design
Seven (7) daytime settings, three (3) night vision settings
IPX8 waterproof rating with drain ports to prevent pooling near lenses
Two step Quick-Detach mount that returns to zero
Adaptable to 1913 rails
ID grid on crumple hood for various identifiers
Lifetime warranty
code:
lp-1
