Model NV009
Classification : Digital Night Vision(Monocular)
Sensor
Type : CMOS
Resolution(pixel) : 1920*1080
Pixel size(μm) : 2.9
Sensitivity(lux) : 0.001
Frame rate(Hz) : 60/30
Image Engine : PARD VLEA
Optics
Objective lens(mm) : 35
Optical Magnification(x) : 4.7
Digital zoom(x) : 1.5-3.0
Continuous digital zoom(x) : 7~14
Field of view (HxV)
Horizontal : 9.1°
Vertical : 5.1°
Diagonal : 10.4°
Focus range : 3m-∞
Eye relief(mm) : 25
Exit pupil(mm) : 6
Diopter adjustment(D) : ± 5D
IR Illuminator
IR Type : VCSEL
IR power(W) : 5
IR illuminating level : 3 Levels
IR distance(m) : 200
IR Wavelength(nm) : 850/940
Display :
Type : OLED
Resolution(pixel) : 1024*768
Color mode : Color/Black&white
Photo / Video
Photo resolution(pixel) : 2592*1944
Photo format : .JPG
Video resolution(pixel) : 1920*1080
Video format : .mp4
Storage(GB) : Micro SD card (Max. 128GB)
Main function
PIP : Yes
E-compass : Yes
Auto recording : Yes
Loop recording : Yes
Time stamp : Yes
Record audio : Yes
Beep sound : Yes
Exposure compensation : Yes
Connections
USB Type-C : Yes
HDMI Output : Yes
WiFi : Yes
Supported Apps : PardVision
Power Supply
Battery type : 18650 Li-ion*1
Output voltage(V) : 3.7
Operating time(h,max) : 8
External power supply(V) : USB Type-C
Environmental characteristic
Degree of protection : IP67
Operating temp(°C/°F) : -20 ~ +50 / -4 ~ +122
Material
Housing : AL6061 & Composite
Objective lens : Glass
Measurement
Product dimension(L x W x H, mm) : 150 x 70 x 38
N.W/pcs(with/without battery, g) : 260/306
code:
nv009-850 ～ nv009-940
