Model : NV007SP(LRF)
Sensor :
Resolution(px) : 2560*1440
Sensitivity(lux) : 0.001Lux
Frame rate(fps) : 30
Optics :
Objective lens : 22.5mm
Optical Magnification(x) : 4x
Digital zoom(x) : 1x-3.5x
PIP zoom(x) : 2x
Continuous digital zoom : 4x-28x
Field of view (HxV) :
22°
12°
25°
Eye relief(mm) : 25mm
Diopter adjustment(mm) : ±5D
Focus range : 3cm-∞
Adaptor diameter(mm) : 45,48
IR Illuminator
IR Type : VCSEL
IR power : 5W
IR illuminating level : 3 levels
IR distance(m) : 350m
IR Wavelength(nm) : 850,940
Display
Type : OLED
Resolution(px) : 1024*768
Reticle Style : -
Reticle Color : -
Color mode : Color,Black&white
Photo / Video
Photo resolution(px) : 2592*1944
Photo format : JPG
Video resolution(px) : 1920*1080
Video format : MP4
Storage(GB) : TF card(128GB MAX)
Main function
LRF detection range(yds) : 1200yds
Red dot : Yes
Self-activated recording : Yes
Auto recording : Yes
Loop recording : Yes
Time stamp : Yes
Record Audio : Yes
Keyboard press sound : Yes
Exposure compensation : Yes
Interfaces
USB Type-C : Yes
HDMI Output : Yes
Connections
WiFi : Yes
Supported Apps : PardVision
Power Supply
Battery type : 18650 Li-ion Battery
Output voltage(V) : 3.7
Operating time(h,max) : 8
External power supply(V) : USB Type-C
Environmental characteristic
Degree of protection : IP67
Operating temp(°C) : -25 – +40
Recoil Power(J) : 6000
Material
Housing : AL6061+Plastic
Objective lens : Glass
Measurement
Product dimension(L x W x H, mm) : 105*120*71/ 105*134*71(LRF version)
code:
nv007sp-850 ～ nv007sp-940/f
