Ranging Capability: 5m – 1200m (5.5 yds – 1312 yds)
Minimum Measuring Time: 0.4s
Distance-to-Target Precision: Better than 1m (3ft)
Distance Units: Meters, Yards, Kilometers, Miles (User-selectable)
Display Type: OLED Digital, 0.96", Energy-efficient, Glare-protected
Compass: High-accuracy Magnetic + Gyro-Compass
Compatible Positioning Systems: GPS, GLONASS, Galileo, EGNOS (select two when ordering)
GPS Location Display: Yes (Displayed in Degrees-Minutes-Seconds)
LRF Wavelength: 905nm (Eye-safe)
Performance to NATO Target (2.3×2.3m): 530m (578 yds, 30% Reflectivity)
Communications: Serial, RS232
Laser Aimer: IR + Red/Green Visible Laser
IR Illuminator: Flood-to-Spot Adjustable
Ballistic Calculator: Yes (up to 12 profiles)
Power Source: 1× CR123 (3V) or External Power Supply (4VDC – 15VDC)
Ranging / Battery Life: Up to 5000 events on 1× CR123 (3V)
Weapon Mountable: MIL-STD-1913 (Picatinny), Recoil-proof
Dimensions: <130×100×60 mm (5.1×3.9×2.3 in)
Weight (with battery and cable): <430 g (<15.1 oz)
Environmental Protection: IP67 or higher
Operating Temperature: -40°C – +50°C (-104°F – +122°F)
Storage Temperature: -50°C – +60°C (-122°F – +140°F)
Warranty: 7 Years
code:
qrf-1200-bc
